PrimaKlima Extractor Fan PK100-TC 280m³/h Temperature Control

The Extractor Fan TC wih Temperature Control is a high efficient temperature controlled in-line duct fans equipped with an ebm-papst AC motor made in Germany. The fan has a temperature controller, as well as an integrated speed controller, which is very useful and spares the additional purchase of an external speed regulation. With its backwards curved blades, the TC-fan generates up to 15% more air flow than common axial fans, and that at a very low power consumption.

The durable and maintenance free ball bearings contribute to a particular smooth engine operation. The fan is equipped with a capacitor motor, which optimally fitted to the housing. The entire housing is made of high-impact-proof, fire-resistant polyamide (nylon).

The temperature is consistently adjustable from 20-30°C, the revolution speed from 0-100%. The temperature sensor is approx. 2m long.

The connections, capacitor, and regulation technology are completely integrated into the housing. The fan comes completely wired.

Technical Details:

• Voltage: 230V 50/60Hz
• Power output: 27 watt
• Amperage: 0,12 A
• Airflow max.: 280m³/h
• Connection diameter: 100 mm
• Max. operation temperature: 50°C
• Weight: approx. 2,38 kg
• Cable length: approx. 2 m
• Dimensions (WxH): 244 x 241 mm

Features:

• AC motor ebm-papst
• Impeller with backward curved blades
• Low power consumption
• Low noise emissions
• Temperature and speed control adjustable
• Impact resistant and durable housing
• Connection and control system in the housing
